AutoCAD – 2D Drafting and 3D Modeling

Course Duration: 3 Month

This 3D and 2D training shows users how to tackle Auto Cad modeling in 3D, and then derive traditional orthographic projection drawings from the 3D part and 3D assembly model(s). It does this with depth and clarity covering auxiliary views, view scaling, professional drawing presentation, block and layer management, and drawing issue administration. In the real world, efficient 3D design relies on using wire and surface methods as well as solids, and the 3D environment behaves the same regardless of the entity types being used. Learning 3D and understanding the AutoCAD 3D environment is straight forward but with a few new principles to grasp. This is made easy by concentrating on entity types that are already familiar which are used to create wire and surface models.

Introducing drawing
Draw tools, Object snap and Auto Snap
Zoom, Pan and templates
The Modify tools
Dimensions and Text
Orthographic and isometric
Blocks and Inserts
Other types of file format
Building drawing
Introducing 3D modeling
3D part and Wire frame Modeling
Surface Modeling
3D models in viewports
The modification of 3D models
